Hoffer Turbine Flowmeter, HO Series Liquid
Images are representations only.

HO Series Liquid Turbine Flowmeter

Brand: Hoffer Flow Controls
Request Information
Favorite

Specifications
  • Low cost
  • Outstanding accuracy
  • Provides wide flow ranges (10:1 to 100:1 turndown ranges available)
  • Wide variety of process connections available
  • Wide selection of construction materials
  • Operate over a wide range of temperatures and pressures

Specifications

Brand

Approvals & Certifications

  • ATEX
  • CE
  • CSA
  • FM Class I, Div. 1, Groups A, B, C, D, Class II/III, Div. 1, Groups E, F, G, Type 4X
  • IEC EX D IIC IP68
  • PED

Bearing Material

  • Ceramic Hybrid Ball Bearings
  • Hard Carbon Composite Sleeve Bearing
  • Tungsten Carbide Sleeve Bearing

Enclosure, Body Material

  • 316 Stainless Steel
  • 316L Stainless Steel

Flange Size - 1-1/2” (DN 40)

  • 1-1/2” (DN 40) - 150#
  • 1-1/2” (DN 40) - 1500#
  • 1-1/2” (DN 40) - 300#
  • 1-1/2” (DN 40) - 600#
  • 1-1/2” (DN 40) - 900#

Flange Size - 1-1/4” (DN 32)

  • 1-1/4” (DN 32) - 150#
  • 1-1/4” (DN 32) - 1500#
  • 1-1/4” (DN 32) - 300#
  • 1-1/4” (DN 32) - 600#
  • 1-1/4” (DN 32) - 900#

Flange Size - 1” (DN 25)

  • 1” (DN 25) - 150#
  • 1” (DN 25) - 1500#
  • 1” (DN 25) - 300#
  • 1” (DN 25) - 600#
  • 1” (DN 25) - 900#

Flange Size - 1/2” (DN 15)

  • 1/2” (DN 15) - 150#
  • 1/2” (DN 15) - 1500#
  • 1/2” (DN 15) - 300#
  • 1/2” (DN 15) - 600#
  • 1/2” (DN 15) - 900#

Flange Size - 1/4” (DN 6)

  • 1/4” (DN 6) - 150#
  • 1/4” (DN 6) - 1500#
  • 1/4” (DN 6) - 300#
  • 1/4” (DN 6) - 600#
  • 1/4” (DN 6) - 900#

Flange Size - 10” (DN 250)

  • 10” (DN 250) - 150#
  • 10” (DN 250) - 1500#
  • 10” (DN 250) - 300#
  • 10” (DN 250) - 600#
  • 10” (DN 250) - 900#

Flange Size - 12” (DN 300)

  • 12” (DN 300) - 150#
  • 12” (DN 300) - 1500#
  • 12” (DN 300) - 300#
  • 12” (DN 300) - 600#
  • 12” (DN 300) - 900#

Flange Size - 2-1/2” (DN 65)

  • 2-1/2” (DN 65) - 150#
  • 2-1/2” (DN 65) - 1500#
  • 2-1/2” (DN 65) - 300#
  • 2-1/2” (DN 65) - 600#
  • 2-1/2” (DN 65) - 900#

Flange Size - 2” (DN 50)

  • 2” (DN 50) - 150#
  • 2” (DN 50) - 1500#
  • 2” (DN 50) - 300#
  • 2” (DN 50) - 600#
  • 2” (DN 50) - 900#

Flange Size - 3” (DN 80)

  • 3” (DN 80) - 150#
  • 3” (DN 80) - 1500#
  • 3” (DN 80) - 300#
  • 3” (DN 80) - 600#
  • 3” (DN 80) - 900#

Flange Size - 3/4” (DN 20)

  • 3/4” (DN 20) - 150#
  • 3/4” (DN 20) - 1500#
  • 3/4” (DN 20) - 300#
  • 3/4” (DN 20) - 600#
  • 3/4” (DN 20) - 900#

Flange Size - 3/8” (DN 10)

  • 3/8” (DN 10) - 150#
  • 3/8” (DN 10) - 1500#
  • 3/8” (DN 10) - 300#
  • 3/8” (DN 10) - 600#
  • 3/8” (DN 10) - 900#

Flange Size - 4” (DN 100)

  • 4” (DN 100) - 150#
  • 4” (DN 100) - 1500#
  • 4” (DN 100) - 300#
  • 4” (DN 100) - 600#
  • 4” (DN 100) - 900#

Flange Size - 5” (DN 125)

  • 5” (DN 125) - 150#
  • 5” (DN 125) - 1500#
  • 5” (DN 125) - 300#
  • 5” (DN 125) - 600#
  • 5” (DN 125) - 900#

Flange Size - 5/8”

  • 5/8” (DN 16) - 150#
  • 5/8” (DN 16) - 1500#
  • 5/8” (DN 16) - 300#
  • 5/8” (DN 16) - 600#
  • 5/8” (DN 16) - 900#

Flange Size - 6” (DN 150)

  • 6” (DN 150) - 150#
  • 6” (DN 150) - 1500#
  • 6” (DN 150) - 300#
  • 6” (DN 150) - 600#
  • 6” (DN 150) - 900#

Flange Size - 8” (DN 200)

  • 8” (DN 200) - 150#
  • 8” (DN 200) - 1500#
  • 8” (DN 200) - 300#
  • 8” (DN 200) - 600#
  • 8” (DN 200) - 900#

NPT Connection

  • 1” NPT Male
  • 1/2” NPT Male
  • 1/4” NPT Male
  • 10” NPT Male
  • 1-1/2” NPT Male
  • 1-1/4” NPT Male
  • 12” NPT Male
  • 2” NPT Male
  • 2-1/2” NPT Male
  • 3” NPT Male
  • 3/4” NPT Male
  • 3/8” NPT Male
  • 4” NPT Male
  • 5” NPT Male
  • 5/8” NPT Male
  • 6” NPT Male
  • 8” NPT Male

Temperature Range

  • -267.8° to 454.4° C (-450° to 850° F)

Tri-Clamp Connection

  • 1” Tri-Clamp
  • 1/2” Tri-Clamp
  • 1/4” Tri-Clamp
  • 1-1/2” Tri-Clamp
  • 1-1/4” Tri-Clamp
  • 2” Tri-Clamp
  • 2-1/2” Tri-Clamp
  • 3” Tri-Clamp
  • 3/4” Tri-Clamp
  • 3/8” Tri-Clamp
  • 5/8” Tri-Clamp
