P Series Rack & Pinion Pneumatic Actuator for VH86 Series

Brand: DK-LOK

Specifications
Actuator operating temperature:
    • Standard: NBR O-Ring -20° to 80° C (-4° to 176° F)
    • Low temperature: Silicon O-Ring -40° to 80° C (-40° to 176° F)
    • High temperature: FKM O-Ring -15° to 150° C (5° to 302° F)
  • Air-pressure psi: 36.26 to 116 (kPa: 250 to 800, bar: 2.5 to 8)
  • Air supply end connection: Female G 1/8" (ISO 228-1)
  • Position indicator is standard

Specifications

Brand

Actuator Type

  • Double-Acting
  • Single-Acting

BSP Connection

  • G 1/8” Female (ISO 228-1)

Enclosure, Body Material

  • 304L Stainless Steel
  • 316L Stainless Steel
  • Extruded Aluminum Alloy with External & Internal Corrosion Protection

O-Ring Material

  • FKM
  • NBR
  • Silicone

Valve Type

  • Normally Closed
  • Normally Open
